Siberia Night Guard 20 inch Single Row
Product description
Boundless innovation from Strands, the Siberia Night Guard range is the solution if you are looking for an LED bar with built-in flash. Fully approved for professional use. In addition to the flash, the bar is of course also equipped with a choice between white and amber position lighting.The bars are available in 5 versions, 12" and 22" double row...
Boundless innovation from Strands, the Siberia Night Guard range is the solution if you are looking for an LED bar with built-in flash. Fully approved for professional use. In addition to the flash, the bar is of course also equipped with a choice between white and amber position lighting.
The bars are available in 5 versions, 12" and 22" double row and 20", 32" and 38" single row.
All are in combi beam version, so the light image is both far and wide.The bar is suitable for both bottom and side mounting.
Connection diagram:
- Black: - Earth
- Red: + LED bar
- Yellow: + amber position light
- Grey: + white position light
- Green: + amber flash
Video:
Show more
Show less
Product specifications
- Article number
- LB313
- Length (cm)
- 50,46
- Height (cm)
- 4,5
- Height incl bracket (cm)
- 6,5
- Depth (cm)
- 5,55
- Weight (gr)
- 1800
- Shape
- Elongated
- Tension
- 9-35V
- Power
- 90W (theoretical) 54W (actual)
- Lumens
- 7560 (theoretical) 2467 (actual)
- Light colour
- Bright white (4500-6000K)
- Number of LEDs
- 18
- Position light function
- Yes, white or amber
- High beam function
- Yes
- Light image
- Combo
- Housing colour
- Black
- Lens colour
- Transparant
- Housing material
- Aluminum
- Lens material
- PC
- Mounting bracket material
- Stainless steel
- Mounting type
- Side / bottom mounting
- Connection
- Cable
- Cable Length (cm)
- 250
- Number of wire cores
- 5
- Operating temperature
- -30°C - +65°C
- IP rating
- IP67 & IP69K
- Certification
- ECE R10, R7, R65, R112
- Packed per
- 1
- Manufacturer article number
- 7323030189600 / 809212
